Series CN3
Series CN6
DS Series
LUXEON M FEATURES & BENEFITS

Uniform image enables tight beam control in MR16 and
spotlight applications
High flux density from a 3mm2 area enables reduced
emitter count and compact fixture designs
11.2V, 5.6V and 2.8V package options puts high
performance within reach with high efficiency and low cost
drivers
Leading thermal resistance allows flexible system design to
optimize for lm/$ and lm/W
Exceeds ENERGY STAR® lumen maintenance
requirements
APPLICATIONS

  • Architecture
  • High Bay & Low Bay
  • Lamps
  • Outdoor
  • Specialty Lighting
  • Spotlights
LUXEON M

LUXEON M is an illumination grade multi-die LED designed to enable
outdoor and industrial applications targeting either high efficiency or low
cost. With Freedom from Binning and leading performance, LUXEON M
falls within a single 3- or 5-step MacAdam ellipse centered in ANSI to
ensure color consistency from LED to LED, delivering high efficacy and
high flux density from a uniform source with tight correlated color
temperature control. The superior quality of light, volume of lumens, and
real world efficacy enable leading performance and efficient solution
development in a wide variety of lighting segments.
Solar CN series
include:
Solar Panels
Pre-wired battery box
Solar Batteries
Charge Controller
LED Fixture
Solar DS series
include:
Solar Panels
Pre-wired battery box
Solar Batteries
Charge Controller
LED Fixture
Piedras Negras Airport, Mexico
Split Series
Solar Street Lamps
All in One Series
Garden Lights
Cylindrical Lights
Garden / Courtyard
Traditional Old School very robust Lights
AC Street Lights
